Indoor FTTH optical fiber cable

1
G652D/G657A optical fiber
2
GFRP/KFRP/Steel strand
3
LZSH jacket
DETAILS

JLOFC-FIGURE8-TYPE CABLES 1,2,4, CORES,
WITH FRP MESSENGER. REINFORCED BY FRP RODS



Product codeFiber optical figure8 type drop cables 1,2,4 cores
With FRP MESSENGER, Reinforced by FRP rods
Cable typeFOC-FTTH+8FRP-LSZH+2FRP-1XG657A1-2X5
FOC-FTTH+8FRP-LSZH+2FPR-2XG657A1-2X5
FOC-FTTH+8FRP-LSZH+2FRP-4XG657A1-2X5
Cable size5.0*2.0±0.2mm
Fiber colorBlue,Orange, Green, Brown
Fiber types9/125(G652D G657A1 G657A2)
Sheath colorBlack (white, gray color upon request)
Sheath materialLSZH
Messenger wireFRP rod. OD=1.0mm
Strength memberSteel rod. OD=0.4mm
Cable weight, kg/kmAppprox 13.5kg
Min.bending radius,mm10(static)
25(dynamic)
Attenuation, dB/km≦0.4 at1310nm
≦0.3 at1550nm
Short term tensile,N300
Crush resistance, N/100mm1000
Operation temperature, ℃-40-+70
Packing1000m or 2000m



1. 100% competitive factory price
2. Professional：24 years focus on optical fiber cable and optical fiber
3. OEM：OEM and Tender support for more than 50 enterprises
4. Reliable：More than 15,000,00 cores km steady supplied every
5. ISO9001, CE, TLC etc certificate
6. Our products used by more than 21 country customers
